Growatt MIN5000TL-X Grid-connected single-phase inverter

Name: Growatt MIN5000TL-X Grid-connected single-phase inverter
SKU: MIN5000TL-X
Availability: InStock

$472.00

Brand Name: Growatt

Model: MIN5000TL-X

Type: Single-phase

SKU: MIN5000TL-X Category: Solar Inverter

MODEL	MIN5000TL-X.
MAX DC POWER	7000W.
MAX DC VOLTAGE(VDC)	550V.
Start voltage	100V.
Nominal voltage	360V.
MPP voltage range	80V-550V.
NO of MPP trackers	2
NO of MPP tracker	1
Max MPP tracker	13.5A
Max. short-circuit current	16.9A
AC nominal power	5000W.
Max. AC apparent power	5000VA.
Nominal AC voltage	230V
AC grid frequency	50/60 Hz
Max. output current	22.7A
Adjustable power factor	0.8leading-0.8lagging.
THDi	<3%
AC grid connection type	Single phase
Max efficiency	98.4%
European efficiency	97.5%
MPPT efficiency	99.9%
DC reverse polarity protection	yes
DC switch	yes
AC/DC surge protection	Type III / Type II
AC short-circuit protection	yes
Ground fault monitoring	yes
Grid monitoring	yes
Anti-islanding protection	yes
AFCI protection	Optional
Dimensions (W / H / D)	375/350/160mm
Weight	10.8kg
Operating temperature range	–25°C – +60°C
Noise emission (typical)	≤35 dB(A)
Nighttime power consumption	< 1W
Topology	Transformerless
Cooling	Natural convection
Protection degree	IP65
Relative humidity	0-100%
Altitude	4000m
DC connection	H4/MC4(Optional)
AC connection	Connector
Display	OLED+LED/WIFI+APP
Interfaces	RS485 / USB / Wi-Fi / GPRS / RF / LAN.
Warranty	5/10
